Automated Vision Screen Printer PV-SP600

(1)The machine comes with specially rotary table，four work station and special drive motor.While high speed and high accuracy printing is in process the cell comes in or out simultaneously eliminsting the cell transport time and results in output of up to 1800 pices of cells per hour.

(2)Specially made pneumatic constan-pressure squeegee system ensures high accuracy printing performance.Automated aqueegee in and out and squeegee pressure is automaticslly adjusted to compensate cell thickness variations.Printing modes can be set according to actual productions.

(3)Actual position of the cell can be adjusted through the special drive motor.Screen adjustment along the X,Y and θdirection is controlled by the vision system and the industrial control competer.

(4)The vision system can inspect the cells before and after printing and align the screen autonmatically.When paper is dirty and needs to be changed ,alarm will be generated and this ensures a clean printing atmosphere.

(5)The handling system ensures smooth transportaion and vertical lift of the cells and can deal with celles of different sizes via simple sdjustment.

全自動視覺印刷機 PV-SP600
（1）采用旋轉平臺設計，四個工作臺，特制驅動馬達，實現高速、高精度印刷的同時，硅片自動進出，省去進出硅片的時間，產量最大達1800片/小時。
（2）特制恒壓氣動印刷刮刀頭，保證高精度印刷，刮刀的進出，及壓力控制，壓力調整能補償硅片厚薄的差異，印刷模式可以根據生產實際情況任意設置。
（3）硅片的實際位置，可以通過特制驅動馬達進行調整，絲網在XYθ方向的調整，通過視覺系統和工控電腦自動控制。
（4）采用視覺系統對硅片進行印刷前后的檢查及絲網的自動居中，及紙臟時報警提示更換，從而保證印刷環境的清潔。
（5）平穩的輸送系統保證硅片的安全輸送及升降，可運用不同尺寸的硅片，只需作很少調整。

Work table automatically lift up and load in the cells.

工作臺自動頂起送進的硅片。

Automated,high speed rotary table equipped with high resolution vision system,can be upgraded to dual printing capability.

旋轉、高速自動平臺；配備高解析度視覺系統；可升級為二次印刷。

Special squeegee head ensures high accuracy printing performance.

高精度印刷，特制刮刀頭。

Rotary table sends out cells at a high speed.

旋轉、高速自動傳送出硅片。
